Center support bearings listed against BMW applications. The carrier bearing holds the midship of a two-piece driveshaft and isolates it from the crossmember through a rubber mount.
28Parts
22In stock
Filters Sort results
Reset Apply
Image | Add | Part Number | Bearing id | Ctr to Ctr of Mount Holes | Center bearing To Base | Application | Bracket wid | Notes |
|---|---|---|---|---|---|---|---|---|
 | 1.181 | 6.300 | 1.750 | BMW | BMW 3 / 5 / Z Series | |||
 | 1.181 | 5.125 | 2.125 | BMW | Mounting Holes 5.125" C/C | |||
 | 1.181 | 5.125 | 1.750 | BMW | ||||
 | 1.181 | 5.250 | 1.750 | BMW | ||||
 | 1.181 | 5.500 | 2.500 | BMW | ||||
 | 1.181 | 4.875 | 1.000 | BMW | ||||
 | 1.181 | 6.300 | 1.650 | BMW | measured from top of bracket to center line | |||
 | 1.181 | 6.300 | 60 | BMW | Aluminum housing .. | |||
 | 1.181 | 6.300 | 500 | BMW | ||||
 | 1.181 | 6.250 | 1.750 | BMW | ||||
 | 1.378 | 6.250 | 250 | BMW | ||||
 | 1.378 | 5.125 | 2.125 | BMW | ||||
 | 1.181 | 6.250 | 1.750 | BMW | ||||
 | 1.181 | 6.300 | 1.625 | BMW | ||||
 | 1.378 | 6.300 | 1.625 | BMW | ||||
 | 1.181 | 5.250 | 2.000 | BMW | ||||
 | 1.378 | 5.681 | 91 | BMW | ||||
 | 1.378 | 6.300 | 500 | BMW | ||||
 | 1.378 | 6.300 | 1.650 | BMW | BMW, Aluminum housing, measured from top of bracket to center | |||
 | 1.378 | 6.875 | 1.875 | BMW | Bearing has offset |
Application is a starting point, not a fitment. The bearing inside diameter has to match the outside diameter of your midship stub, and the mount hole spacing has to match your crossmember bracket.
On a two-piece driveshaft the center support bearing carries the midship where the two sections meet. A sealed ball bearing runs on the stub shaft and sits inside a rubber isolator, which takes out driveline vibration before it reaches the chassis. When the rubber perishes or the bearing dries out, the symptom is usually a vibration or rumble that changes with road speed rather than engine speed.
Ordering by vehicle narrows the field but does not close it, because a single model can use more than one carrier across model years and driveline options. Measure the stub outside diameter and the centre-to-centre spacing of the bracket holes, then match those figures on the part page.
