2780-16 – Center Support Bearing – Bmw Application – 1.378″ ID – 250″ Center Bearing To Base
$68.47
0 in stock
Description
BMW application center support bearing with 1.378″ bore and 0.250″ center-to-base height; minimal-drop rubber-isolated assembly for flush-mount BMW propshaft hanger brackets.
Full Description
| SKU | 2780-16 |
|---|---|
| Application | BMW (confirm via chassis code) |
| Bore ID | 1.378" (35 mm) |
| Center to Base | 0.250" |
| Type | Rubber-isolated center support bearing |
- 0.250" is the smallest center-to-base height in the 2780 BMW series -- used where the crossmember is virtually flush with the propshaft centerline
- Any mounting that substitutes a taller unit raises the propshaft above its designed axis, creating a constant-velocity angle error at the center joint
- Bore ID 1.378" (35 mm) -- verify OD of stub shaft journal before installation
- Fastener access may be restricted at this height -- use a low-profile torque wrench or a crowfoot fitting to reach the bracket bolts
Warning: at 0.250" center-to-base height, the bracket base flange is almost directly against the bearing outer housing. Over-torquing the bracket bolts will squeeze the rubber isolator between the flange faces, permanently compressing and hardening the isolator material. Torque to spec only -- typically 20--25 Nm for M8 fasteners on BMW propshaft brackets.
Additional information
| Application | BMW |
|---|---|
| Bearing id | 1.378 |
| Center bearing to base | 250 |
| Ctr to ctr of mount holes | 6.250 |
| Partn number | 2780-16 |
