3R-3-9165KX Slip Yoke 3R 3R03-32 , Center Line To End: 7.205 Splines Diameter: 1.375 Splines Count: 28/32
$30.83
21 in stock
Description
3R-3-9165KX slip yoke — 3R series, 1.375″ x 31/32 spline, 7.375″ center-to-end. Confirm spline count on transmission output shaft.
Full Description
The 3R series is a retrofit/crossover U-joint series used where a standard series yoke does not fit the application. The designation 3R03-32 refers to a specific bearing cup and trunnion geometry. The 3R-3-9165KX slip yoke in this series carries an unusual 31/32-spline count designation, which differs from the more common 16, 28, or 32-spline configurations seen on domestic applications.
The 7.375" CL-to-end makes this a long-body slip yoke. Length in a slip yoke serves two purposes: it provides engagement depth in the transmission tailshaft housing at full droop, and it gives adequate spline engagement over the full range of suspension travel. Long yokes are typical in applications with significant suspension articulation.
| Specification | Value |
|---|---|
| Part Number | 3R-3-9165KX |
| Series | 3R (3R03-32) |
| Spline Diameter | 1.375" |
| Spline Count | 31/32 |
| CL-to-End | 7.375" |
The 31/32 count is a split designation that may indicate a matching requirement with a specific output shaft. Confirm the exact spline count on your application. Do not rely on visual estimation - count each spline individually or use a spline gauge. See also 3R-3-9170KX for comparison of the same series with different dimensions.
All slip yokes listed by series.
Additional information
| Partn number | 3R-3-9165KX |
|---|---|
| Series | 3 R |
| Splines count | 31/32 |
| Splines dia | 1.375 |
| Center u joint to end | 7.375 |
