2-3-6061KX Slip Yoke 1310 series, Splines: 1.500×16 Center Joint To End 6.875 Heavy Duty
$61.25
+50 in stock
11
People watching this product now!
Description
2-3-6061KX 1310 series heavy-duty slip yoke. 1.500 in (38.1 mm) x 16 spline, 6.875 in center U-joint to end. Verify stop shaft spline diameter and count before ordering.
Full Description
2-3-6061KX 1310 Series Slip Yoke — Heavy Duty
The 2-3-6061KX is a 1310 series heavy-duty slip yoke with a 1.500-inch (38.1 mm) spline diameter and 16-spline count. The centerline-to-end dimension is 6.875 inches. The metric equivalent of the spline spec is 38.1 x 16, as noted in the product data. This yoke slides over the stop shaft at the front of the driveshaft, providing the axial travel needed as the suspension cycles.
Specifications
- Part Number: 2-3-6061KX
- Series: 1310
- Spline Diameter: 1.500 in (38.1 mm)
- Spline Count: 16
- Center U-Joint to End: 6.875 in
- Note: Splines 38.1 x 16 (metric equivalent)
When fitting the 2-3-6061KX, verify the stop shaft diameter is 1.500 inches (38.1 mm) with 16 splines. The larger 1.500-inch bore distinguishes this yoke from standard 1310 slip yokes, which typically run a 1.250-inch or 1.375-inch diameter. Confirm the stop shaft matches this heavier specification before ordering. The 6.875-inch CJ-to-end provides a deep engagement profile suited to applications with significant suspension travel.
Despite the heavy-duty spline sizing, the 2-3-6061KX interfaces with standard 1310 series U-joints at the ear end. Confirm U-joint series compatibility throughout the driveshaft assembly. The metric designation 38.1 x 16 may be used when cross-referencing against metric parts catalogs for this yoke.
Additional information
| Series | 1310 |
|---|---|
| Notes | SPLINES: 38.1X16 ( In Metric ) |
| Partn number | 2-3-6061KX |
| Splines dia | 1.500 |
| Splines count | 16 |
| Center u joint to end | 6.875 |
