Brand:
2-3-128KX – Slip Yoke – 1310 Series – 1.375″ Splines Dia – Center U Joint To End 5.375 SPICER
$89.48
3 in stock
17
People watching this product now!
Description
2-3-128KX SPICER 1310 series short slip yoke. Spline diameter 1.375″, 16 splines, center U-joint to end 5.375″. Designed for industrial driveshaft applications — verify stub shaft spline specs before ordering.
Full Description
2-3-128KX Slip Yoke — SPICER 1310 Series
The 2-3-128KX slip yoke from SPICER is a 1310 series component designed for use on the splined stub shaft (stop shaft) welded to the front driveshaft section in industrial driveshaft assemblies. This is a short slip yoke configuration used on industrial shafts, providing the telescoping engagement necessary to accommodate axial movement in the driveline.
Specifications
- Part Number: 2-3-128KX
- Brand: SPICER
- Series: 1310
- Spline Diameter: 1.375"
- Spline Count: 16
- Center U-Joint to End: 5.375"
- Configuration: Short slip yoke
- Application: Industrial driveshafts
When sourcing the SPICER 2-3-128KX slip yoke, verify the stub shaft spline diameter (1.375") and spline count (16 splines) against the existing driveshaft assembly. The 5.375" center U-joint to end dimension is the critical measurement for confirming fitment on the stop shaft. The 1310 series rating places this yoke in the light-to-medium duty torque range — confirm series compatibility with the mating U-joint and companion yoke before installation.
This SPICER part is manufactured to OEM tolerances for industrial shaft applications requiring a short-body slip yoke design. Cross-reference part number 2-3-128KX with your driveshaft assembly specifications to confirm dimensional compatibility.
Additional information
| Center u joint to end | 5.375 |
|---|---|
| Notes | short slip yoke. Used on industrial shafts. |
| Partn number | 2-3-128kx |
| Series | 1310 |
| Splines count | 16 |
| Splines dia | 1.375 |
| Brand | SPICER |
More Parts from the same Category
Filters Sort results
Reset Apply
Image | Part # | Part Details | Price | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Slip Yoke (100) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | Center u joint to end 9.681 Notes Spicer Partn number 100-3-41X Series SPL100 ⋅ SPL90 Splines count 29.30 Splines dia 1.965 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | Center u joint to end 9.000 Series 1351-20 Splines count 16 Splines dia 1.500 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | Center u joint to end 7.500 Notes Does not fit all Toyota OEM 20 spline stubs. Toyota truck Partn number 1303-20 Series 1351-20 Splines count 20 Splines dia 1.310 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | Center u joint to end 9.875 Notes Toyota truck/Land Cruiser This part is only sold in Kit 1343-20L Partn number 1303-20L Series 1351-20 Splines count 20 Splines dia 1.310 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | Center u joint to end 6.00 Notes Toyota Land Cruiser Partn number 1303-21 Series 1351-20 Splines count 20 Splines dia 1.310 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | Center u joint to end 4.313 Notes brisitish imports Partn number 1403-16 Series 1100 Splines count 16 Splines dia 1.063 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | Center u joint to end 5.375 Partn number 1703-16 Series 1751 Splines count 16 Splines dia 1.063 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | Center u joint to end 8.016 Series 1210 Splines count 16 Splines dia 1.250 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | Center u joint to end 5.375 Notes short slip yoke. Used on industrial shafts. Partn number 2-3-128kx Series 1310 Splines count 16 Splines dia 1.375 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 | Center u joint to end 6.724 Notes dust cap 211121X Partn number 2-3-15101x Series 1310 Splines count 18/20 Splines dia 1.338 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
