1303-16 Slip Yoke 1351-20 Series Toyota ISR 29×52 series, Splines: 1.500×16 , Centerline To End: 9 Inch
$49.52
9 in stock
10
People watching this product now!
Description
1303-16 1351-20 series slip yoke for Toyota ISR 29×52 applications. 1.500 in x 16 spline, 9.000 in center U-joint to end. Verify stop shaft spline specs before ordering.
Full Description
1303-16 1351-20 Series Slip Yoke — Toyota ISR 29x52
The 1303-16 is a 1351-20 series slip yoke with a 1.500-inch spline diameter and 16-spline count. The centerline-to-end dimension is 9.000 inches, making this one of the longer slip yoke configurations in this series. The 1351-20 series corresponds to the Toyota ISR (29 x 52 mm) U-joint specification used on Toyota truck and 4WD driveshafts.
Specifications
- Part Number: 1303-16
- Series: 1351-20 (Toyota ISR 29x52)
- Spline Diameter: 1.500 in
- Spline Count: 16
- Center U-Joint to End: 9.000 in
When fitting the 1303-16, confirm the stop shaft spline diameter is 1.500 inches with 16 splines. The 9.000-inch CJ-to-end provides an extended engagement depth, suitable for applications requiring significant driveshaft plunge. The 1351-20 Toyota ISR series uses a 29 x 52 mm U-joint cap dimension — confirm the mating U-joint matches this specification rather than a standard SAE 1350 or 1310 series joint.
The 1303-16 is used on Toyota vehicles that use the ISR (29 x 52) U-joint standard. Substituting a non-ISR yoke with a different cap diameter will result in a loose or non-fitting U-joint cross. Verify the stop shaft and U-joint specs match the 1351-20 Toyota ISR standard before ordering.
Additional information
| Center u joint to end | 9.000 |
|---|---|
| Series | 1351-20 |
| Splines count | 16 |
| Splines dia | 1.500 |
