SA68740S Slip Assembly 47.6×135 68740/2040 Series , Butt Diameter: 114.25 Center Line To Weld 255mm

SA68740S UDS 68740 Series Slip Assembly

The SA68740S is a UDS steel slip assembly for the 68740 / 2040 series, with a 47.6 x 135 mm spline profile. The butt diameter is 114.25 mm and the centerline-to-weld dimension is 255 mm. This assembly fits a 120 x 3 mm tube and is used in heavy-duty or commercial driveshaft applications requiring the 68740 series slip interface.

Specifications

• Part Number: SA68740S
• Brand: UDS
• Series: 68740 / 2040
• Material: Steel
• Spline Profile: 47.6 x 135 mm
• Butt Diameter: 114.25 mm
• Centerline to Weld: 255 mm
• Fits Tube: 120 x 3 mm

When fitting the SA68740S, confirm the driveshaft tube OD is 120 mm with a 3 mm wall thickness. The 114.25 mm butt diameter pilots into the tube bore; verify the tube cut is square and the bore is within tolerance before welding. The 255 mm CL-to-weld must be included when calculating overall driveshaft length for the specific vehicle application.

The SA68740S is built around the 68740/2040 series specification, which is a metric heavy-duty series used on commercial trucks and buses in markets where metric driveshaft standards are prevalent. Confirm the mating yoke and U-joint are also 68740/2040 series to maintain dimensional compatibility throughout the driveshaft assembly. Verify tube OD and wall spec before welding.
