3-3-6081X – Transmission Yokes – 1350 Series – 26/27 X 1.176 Splines – 1.500″ Hub Dia
$212.65
1 in stock
Description
3-3-6081X 1350 series TH350 transmission yoke, 26/27-spline x 1.156″ diameter, 5.469″ centerline to U-joint, 1.500″ hub diameter.
Full Description
- Part Number
- 3-3-6081X
- Series
- 1350
- Application
- TH350
- Splines
- 26/27 x 1.156"
- C/U-joint to End
- 5.469"
- Hub Diameter
- 1.500"
- Counterbore
- None
The standard steel 3-3-6081X is the non-performance equivalent of the forged chromoly T3-3-6081HP. Both share the same spline profile and length -- the distinction is construction material and cost. For street applications below approximately 500 lb-ft at the driveshaft, the standard steel version is adequate. Above that threshold, consider the chromoly variant.
The 26/27-spline TH350 output is one of the most common yoke applications in the GM driveline catalog -- this yoke fits virtually all TH350 transmissions from 1969-1984. The 5.469" C/U-joint to end is the standard length; compare with T3-3-6081H (5.810") for Powerglide roller bearing applications that need the slightly longer version. Always confirm the yoke retaining nut torque specification for the TH350 -- a loose nut is among the most common causes of premature spline wear on this transmission family. Pair with a 1350 U-joint.
Alternative parts:
Additional information
| Center u joint to end | 5.469 |
|---|---|
| Counter bore dia | |
| Hub dia | 1.500 |
| Notes | TH350 |
| Partn number | 3-3-6081X |
| Series | 1350 |
| Splines count dia | 26/27 X 1.176 |
