3-3-1601KX Slip Yoke 1480 Series, Splines: 1.562 x 16 , Centerline To End 6.812
$45.13
+50 in stock
19
People watching this product now!
Description
3-3-1601KX UDS 1480 series slip yoke, 16 splines x 1.562″ diameter, CJ-to-end 6.812″. Verify spline count and diameter against stop shaft before ordering.
Full Description
3-3-1601KX UDS 1480 Series Slip Yoke 16 Splines x 1.562 Diameter
The 3-3-1601KX is a 1480 series slip yoke manufactured by UDS. It carries 16 splines at 1.562" diameter with a centerline-to-end (CJ-to-end) dimension of 6.812".
Specifications
- Part Number: 3-3-1601KX
- Brand: UDS
- Series: 1480
- Splines Count: 16
- Splines Diameter: 1.562"
- Center UJ to End: 6.812"
When fitting the 3-3-1601KX, confirm the transmission or transfer case output stop shaft carries 16 splines at 1.562" diameter. The 6.812" CJ-to-end dimension sets the working geometry at the transmission end of the driveshaft; compare this against the available space and required driveshaft length before ordering. The 1480 series cap dimensions at the U-joint end must match the U-joint and weld yoke used on the driveshaft.
The 1480 series provides higher torque capacity than the 1410 and is specified for heavy-duty truck and commercial vehicle drivelines. The 3-3-1601KX is the UDS variant; the 1562" spline diameter at 16 splines is a specific combination — do not substitute a yoke with the same spline count but different diameter. Confirm the complete series (U-joints, weld yokes, flange yokes) is consistent at 1480 before ordering this slip yoke.
Additional information
| Center u joint to end | 6.812 |
|---|---|
| Partn number | 3-3-1601KX |
| Series | 1480 |
| Splines count | 16 |
| Splines dia | 1.562 |
| Brand | UDS |
