3503-315 – Transmission Yokes – 1350 Series – 30/31 X 1.391 Splines – 1.685″ Hub Dia
$90.44
1 in stock
Description
3503-315 1350 series full-spline transmission yoke, 30/31-spline x 1.391″ diameter, 7.250″ centerline to U-joint, 1.685″ hub.
Full Description
Spec Summary: 3503-315 -- 1350 Series | Full Spline | 30/31-Spline x 1.391" | C/U-joint to End 7.250" | Hub 1.685" | No Counterbore
3503-315 is the longer version of 3503-316 -- same spline, hub, and construction, but 1.250" more slip travel (7.250" versus 6.000"). The extra length accommodates longer driveshaft applications or vehicles where suspension movement requires more slip travel than the shorter yoke provides. Choosing between 3503-315 and 3503-316 is entirely a function of driveshaft measurement -- use the longest yoke that still provides adequate engagement at full jounce.
The 1.685" hub on both parts is specific to transmissions with this output bore -- confirm your application uses this hub OD. Full-spline engagement provides maximum surface area for torque transfer, which is the preferred configuration for high-cycle or high-torque applications. Replace the output seal when installing this yoke and apply grease to the spline bore before engagement.
Additional information
| Center u joint to end | 7.250 |
|---|---|
| Counter bore dia | |
| Hub dia | 1.685 |
| Notes | Full Spline |
| Partn number | 3503-315 |
| Series | 1350 |
| Splines count dia | 30/31 X 1.391 |
