Brand:
3-53-1361 Midship Slip Yoke , Splines: 1.375×16 , Fits: 3.000×0.083 Tube, Weld To End: 8.094 Butt Diameter: 2.844
$31.73
7 in stock
14
People watching this product now!
Description
3-53-1361 UDS slip midship yoke. Splines: 16×1.375″, tube 3.000″x0.083″, butt dia 2.844″, end-to-weld 8.094″, bearing dia 1.378″. Verify spline count and bearing ID before ordering.
Full Description
3-53-1361 UDS Midship Slip Yoke 16x1.375" Splines 3.000" x 0.083" Tube 8.094" Weld-to-End
The 3-53-1361 is a UDS slip-style midship yoke with 16 splines at 1.375" diameter. It fits 3.000" OD tube with a 0.083" wall, has a butt diameter of 2.844", a spline length of 4.969", an end-to-weld length of 8.094", and a bearing journal diameter of 1.378".
Specifications
- Part Number: 3-53-1361
- Brand: UDS
- Style: Slip
- Splines Count x Diameter: 16 x 1.375"
- Spline Length: 4.969"
- Tube OD: 3.000"
- Tube Wall: 0.083"
- Butt Diameter: 2.844"
- End to Weld: 8.094"
- Bearing Diameter: 1.378"
When fitting the 3-53-1361, confirm the driveshaft tube OD is 3.000" with a 0.083" wall. The 2.844" butt diameter is the weld shoulder — square-cut and deburr the tube before welding. The 1.378" bearing journal must match the bore ID of the center support bearing installed on your application.
The 3-53-1361 has a notably long spline engagement length of 4.969" — significantly longer than the 3-53-1371 (4.438" spline length) and 2-40-2051 (2.250"). This extended spline engagement provides greater telescoping travel. All three units share the 16x1.375" spline specification; differentiate between them by comparing tube wall (0.083" for 3-53-1361 versus 0.065" for 2-40-2051) and end-to-weld length for your specific application.
Additional information
| Tube dia | 3.000 |
|---|---|
| Tube wall | 0.083″ |
| Butt dia | 2.844 |
| Splines length | 4.969 |
| End to weld | 8.094 |
| Bearing dia | 1.378 |
| Brand | UDS |
| Splines count dia | 16 X 1.375 |
| Style | Slip |
