2-40-2051 Midship Slip Yoke , Splines: 1.375×16 , Fits: 3.000×0.065 Tube, Weld To End: 7.625
$44.73
7 in stock
15
People watching this product now!
Description
2-40-2051 UDS slip midship yoke. Splines: 16×1.375″, tube 3.000″x0.065″, butt dia 2.875″, end-to-weld 7.625″. Verify spline count, tube OD and wall before ordering.
Full Description
2-40-2051 UDS Midship Slip Yoke 16x1.375" Splines 3.000" x 0.065" Tube 7.625" Weld-to-End
The 2-40-2051 is a UDS slip-style midship yoke with 16 splines at 1.375" diameter. It fits 3.000" OD tube with a 0.065" wall, has a butt diameter of 2.875", a spline length of 2.250", and an end-to-weld length of 7.625".
Specifications
- Part Number: 2-40-2051
- Brand: UDS
- Style: Slip
- Splines Count x Diameter: 16 x 1.375"
- Spline Length: 2.250"
- Tube OD: 3.000"
- Tube Wall: 0.065"
- Butt Diameter: 2.875"
- End to Weld: 7.625"
When fitting the 2-40-2051, confirm the driveshaft tube OD is 3.000" with a 0.065" wall before cutting to length. The 2.875" butt diameter is the weld shoulder; tube must be square-cut and deburred to seat against this shoulder. The 7.625" end-to-weld length is the total yoke length from spline tip to weld shoulder — use this to calculate the assembled contribution to overall driveshaft length.
The 16x1.375" spline on the 2-40-2051 must match the mating stub shaft or midship shaft spline specification exactly. Compare the 2-40-2051 against the 3-53-1361 and 3-53-1371, which share the same 16x1.375" spline and 3.000" tube OD with 0.083" wall — the 2-40-2051 runs 0.065" wall versus 0.083" for those units. Confirm tube wall thickness on your application before selecting between these midship yokes.
Additional information
| Tube dia | 3.000 |
|---|---|
| Tube wall | 0.065″ |
| Splines length | 2.250 |
| End to weld | 7.625 |
| Brand | UDS |
| Style | Slip |
| Splines count dia | 16 X 1.375 |
| Butt dia | 2.875 |
