S3-3-1641KX – Slip Yoke – 1480 Series – 1.562″ Splines Dia – Center U Joint To End 9.500
$228.48
48 in stock
13
People watching this product now!
Description
S3-3-1641KX UDS 1480 series slip yoke. Splines: 16, CJ-to-end: 9.500″. Verify stop shaft spline count and diameter before ordering.
Full Description
S3-3-1641KX UDS 1480 Slip Yoke
The S3-3-1641KX is a 1480 series slip yoke manufactured by UDS. The slip yoke slides over the stop shaft — the splined stub welded onto the front section of the driveshaft tube — and telescopes in and out as the suspension cycles. This allows the driveshaft to change working length without binding.
The spline specification is 16; verify this matches the stop shaft before ordering. The centerline-to-end dimension is 9.500 inches, measured from the U-joint centerline to the open end of the spline bore. This controls minimum engagement depth under full suspension droop — ensure sufficient spline overlap remains at maximum driveshaft extension. Spicer. The 1480 series ranks above 1410 in torque capacity, with a 1.375-inch cap diameter, suited for heavy-duty commercial trucks and large SUVs.
Specifications
- Part Number: S3-3-1641KX
- Brand: UDS
- Series: 1480
- Center u joint to end: 9.500
- Notes: Spicer
- Splines count: 16
- Splines dia: 1.562
Fitment & Installation Notes
When selecting the S3-3-1641KX, verify the stop shaft spline count and diameter match the 16 specification. Inspect the stop shaft for wear or damage; a worn shaft will produce lash even with a new yoke.
View the full range of Slip Yoke in 1480 and adjacent series configurations.
Additional information
| Center u joint to end | 9.500 |
|---|---|
| Notes | Spicer |
| Partn number | S3-3-1641KX |
| Series | 1480 |
| Splines count | 16 |
| Splines dia | 1.562 |
