2826-101 Weld Tube Yoke 1751 Series, Fits: 1.000 x 0.120 , Butt Dia: 0.967 Inch Front Mercedes Driveshaft
$36.10
4 in stock
14 People watching this product now!
Description
2826-101 UDS 1751 series steel weld yoke for Mercedes front driveshaft. Fits 1.000 in OD x 0.120 in wall tube, 0.967 in butt dia, 1.675 in CL-to-weld.
Full Description
2826-101 UDS 1751 Series Weld Tube Yoke — Mercedes Front Driveshaft
The 2826-101 is a UDS 1751 series steel weld tube yoke used for the Mercedes front driveshaft. It fits a 1.000-inch OD x 0.120-inch wall tube, with a butt diameter of 0.967 inches and a centerline-to-weld dimension of 1.675 inches. This is a small-diameter, thick-wall yoke specification corresponding to the compact front driveshaft assemblies found on Mercedes vehicles.
Specifications
- Part Number: 2826-101
- Brand: UDS
- Series: 1751
- Material: Steel
- Tube Diameter x Wall: 1.000 in x 0.120 in
- Butt Diameter: 0.967 in
- Center U-Joint to Weld: 1.675 in
- Application: Mercedes Front Driveshaft
When fitting the 2826-101, the 1.000-inch OD with a 0.120-inch wall leaves an ID of approximately 0.760 inches — the 0.967-inch butt diameter is designed to fit snugly against the tube end face rather than inside it. Confirm the tube cut is square and the tube OD matches exactly before welding. The 1.675-inch CL-to-weld must be accounted for when calculating overall front driveshaft length on Mercedes applications.
The 2826-101 is a 1751 series part intended specifically for Mercedes front driveshaft rebuilds. The 1751 series uses metric-influenced U-joint dimensions; verify the mating U-joint series and cap dimensions match the yoke ears before assembly. Do not substitute a standard SAE series yoke on this application.
Additional information
| Butt dia | 0.967 |
|---|---|
| Center u j to weld | 1.675 |
| Material | STEEL |
| Notes | Used For Mercedes Front DS |
| Partn number | 2826-101 |
| Series | 1751 |
| Tube dia wall | 1.000×0.120 |
| Brand | UDS |
