2752-1091 – CV Joint Kit – Bolt Hole Count 6″ – Outer Dia 108mm – Splines Dia 28.35mm
$175.69
1 in stock
13 People watching this product now!
Description
2752-1091 Cv Joint Kit — Rzeppa, 108mm OD | 28.35mm x 34 spline | 26.1mm inner race | 28mm outer race. Proven complete replacement kit, all components matched.
Full Description
The 2752-1091 CV joint kit is a complete Rzeppa constant velocity joint assembly — inner race, outer race, ball bearings, cage, and all required hardware. It replaces the full CV joint as a unit, not just one component. The 2752-1091 CV joint kit is dimensioned for one specific application: outer diameter, spline count, and race widths are all matched and verified.
2752-1091 Cv Joint Kit — Rzeppa Specs & Fitment
The 2752-1091 CV joint kit specs: 108mm OD | 28.35mm x 34 spline | 26.1mm inner race | 28mm outer race. Land Rover. Outer diameter determines fit in the housing bore. Spline count determines shaft engagement. Inner and outer race widths determine how the assembly stacks in the housing — all four specs must match. Substituting races from different part numbers causes uneven load distribution and early failure.
Pack the 2752-1091 CV joint kit thoroughly with CV grease during installation — fill the inner race cavity before seating the cage. CV joint failures from grease starvation happen faster than mechanical wear. Don't use wheel bearing grease — use CV-specific grease rated for the operating angle of your application.
Key Features
- Style: Rzeppa — constant velocity design, smooth power transfer at operating angle
- Outer dia: 108mm — must fit housing bore exactly
- Spline: 28.35mm x 34 — shaft engagement spec
- Inner race width: 26.1mm
- Outer race width: 28mm
- Complete kit — all components matched and measured for correct assembly
- Note: Land Rover
Specifications
- SKU: 2752-1091
- Brand: UDS
- Style: Rzeppa
- Outer Dia: 108mm
- Spline Dia: 28.35mm
- Spline Count: 34
- Inner Race Width: 26.1mm
- Outer Race Width: 28mm
- Notes: Land Rover
Additional information
| Bolt hole count | 6 |
|---|---|
| Bolt hole dia | 10.4mm |
| Boot cap part | INCLUDED |
| Gasket | INCLUDED |
| Inner race width | 26.1mm |
| Outer dia | 108mm |
| Outer race width | 28mm |
| Splines count | 34 |
| Splines dia | 28.35mm |
| Notes | Land Rover |
| Partn number | 2752-1091 |
