Stub & Midship Shaft
More categories:
Filters Sort results
Reset Apply
Image | Add | Part # | Tube Dia | Tube Wall | Butt Dia | Splines Length | End To Weld | Spline Count And Dia | Style | Bearing dia | Brand | Notes |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 4.500" | 0.134" | 4.234 | 4.500 | 11.250 | 16 X 3.000 | Slip | |||||
 | 2.750" | 0.065" | 2.625 | 3.500 | 9.615 | 31/32 X 1.375 | Slip | 1.378 | ||||
 | 2.500 | 0.083" | 2.344 | 1.011 | 5.750 | 24 x 0.972 | CVJ | 1.181 | USE WITH: 2752-9401 - plunge cvj set up with 3626-252 cvj weld yoke | |||
 | 4.500" | 0.259 | 3.984 | 4.500 | 11.531 | 16 X 3.000 | Slip | |||||
 | 4.500" | 0.259 | 3.984 | 4.500 | 9.906 | 16 X 3.000 | Slip | |||||
 | N/A | N/A | N/A | 7.375 | 11.750 | 16 X 1.375 | CVJ | Dual spline stub for 3152-1001 CVJ on 1 end and standard 16/1.375"" spline on the other end used with: 3133-161 | ||||
 | 4.000 | 0.095" | 3.821 | 4.000 | 10.000 | 30 X 1.937 | Slip | 1.968 | Spicer | |||
 | 4.500" | 0.259 | 3.984 | 2.750 | 5.438 | 16 X 2.350 | FIXED | 2.362 | Spicer |
Category Information
A stub shaft or midship shaft is the center section of a three-piece driveshaft assembly, or the short connecting shaft between a center support bearing and an adjacent U-joint. In applications where the driveline geometry requires a third pivot point between the transmission and the rear axle — common in long-wheelbase trucks, buses, and commercial vehicles — a stub or midship shaft carries the bearing journal for the center support bearing and provides the splined interface for the adjacent slip assembly or weld yoke.
Stub shaft selection requires:
Spline count and diameter — must match the mating slip collar or yoke exactly
Bearing journal OD — the polished diameter where the center support bearing inner race rides
Overall length — determines the driveshaft geometry between the two adjacent U-joints
Series — sets the U-joint bore at the yoke end
Universal Driveshafts stocks stub shafts and midship shafts for commercial vehicle, agricultural, and industrial applications. Our listings include full dimensional specs — spline count, spline diameter, bearing journal OD, and overall length — so you can confirm fit against your existing component or engineering drawing before ordering.
