IC35 – Increase Bushing – Length 0.9″ – From Tube 2-120 – Inside Dia 1.764″ – Outer Dia 3″

IC35 Increase Bushing 2-120 to 3-083

The IC35 is a driveshaft increase bushing transitioning from a 2-120 tube (2.0" OD x 0.120" wall) to a 3-083 tube (3.0" OD x 0.083" wall). Inside diameter is 1.764", outer diameter is 3.0", and length is 0.9".

Specifications

• Part Number: IC35
• From Tube: 2-120
• To Tube: 3-083
• Inside Diameter: 1.764"
• Outer Diameter: 3.0"
• Length: 0.9"

When fitting the IC35, confirm the existing tube is 2.0" OD x 0.120" wall (2-120) and the target tube is 3.0" OD x 0.083" wall (3-083). The 1.764" ID is sized for the heavy-wall 2-120 tube. The 0.120" wall reduces the effective ID compared to the 2-083 tube used in the IC36 (1.834" ID). Verify the tube wall is 0.120" before insertion.

The IC35 and IC36 are not interchangeable despite both having the same 3.0" OD, because the ID differs (1.764" vs 1.834"). The IC35 is specific to the heavy-wall 2-120 inner tube. Match the bushing to the specific tube wall specification.

The IC35 ID of 1.764" and OD of 3.0" are the critical dimensions. Confirm both the 2-120 (inner) and 3-083 (outer) tube specifications before ordering. Using a bushing with the wrong ID will prevent the inner tube from seating, compromising the weld joint.
