IC32 – Increase Bushing – From Tube 25-095 – Inside Dia 2.31″ – Outer Dia 3″ – To Tube 3-083

IC32 Increase Bushing 25-095 to 3-083

The IC32 is a driveshaft increase bushing transitioning from a 25-095 tube (2.5" OD x 0.095" wall) to a 3-083 tube (3.0" OD x 0.083" wall). Inside diameter is 2.31", outer diameter is 3.0".

Specifications

• Part Number: IC32
• From Tube: 25-095
• To Tube: 3-083
• Inside Diameter: 2.31"
• Outer Diameter: 3.0"

When fitting the IC32, confirm the existing tube is 2.5" OD x 0.095" wall (25-095) and the target tube is 3.0" OD x 0.083" wall (3-083). The 2.31" ID reflects the 0.095" wall of the 25-095 tube. This differs from the IC38 (2.334" ID, for 25-083 tube with 0.083" wall). The thicker 0.095" wall reduces the effective bore, requiring the smaller ID on the IC32.

If the existing tube is the lighter 25-083 (0.083" wall), the IC38 applies instead. The IC32 ID of 2.31" is not correct for a 25-083 tube and will result in loose fitment.

The IC32 ID of 2.31" and OD of 3.0" are the critical matching dimensions. Verify both tube specifications (25-095 inner and 3-083 outer) before ordering. Substituting the IC38 (designed for 25-083, 2.334" ID) in a 25-095 application results in an oversized ID and incomplete inner tube seating.
