6-4-7181-1X – End Yoke – 46 x 2.390″ Splines – 5.391″ Cj To End – 3.250″ Hub Dia – Partn Number 6-4-7181X
$397.20
1 in stock
11
People watching this product now!
Description
6-4-7181X 1710 BP end yoke. Splines: 46 at 2.390″ dia, hub dia 3.250″, CJ-to-end 5.391″. Verify spline count and diameter against output shaft before ordering.
Full Description
6-4-7181X 1710 BP End Yoke 46 Splines 2.390" Dia 3.250" Hub 5.391" CJ-to-End
The 6-4-7181X is a 1710 series BP (bolt-plate) style end yoke with 46 splines at 2.390" diameter. It has a hub diameter of 3.250", a CJ-to-end dimension of 5.391", and a through-hole diameter of 2.328".
Specifications
- Part Number: 6-4-7181X
- Series: 1710
- Style: BP (Bolt-Plate)
- Splines Count: 46
- Spline Diameter: 2.390"
- Hub Diameter: 3.250"
- CJ to End: 5.391"
- Through Hole: 2.328"
When fitting the 6-4-7181X, verify the differential or axle output shaft has 46 splines at 2.390" diameter — this is a higher spline count than the 6-4-7631-1X (39 splines at 2.024"). The 3.250" hub diameter is larger than the 6-4-7631-1X's 3.000" hub, indicating a different bearing retention bore in the housing. Confirm hub diameter against your housing bearing bore before ordering.
The BP (bolt-plate) style on the 6-4-7181X uses a bolt-retained U-joint cap system rather than snap rings — confirm your 1710 series U-joint is compatible with the BP yoke configuration. The 2.328" through-hole is slightly larger than the 6-4-7631-1X's 2.312" — verify axle shaft OD clearance through the hub before ordering the 6-4-7181X. The part number listed in the product name is 6-4-7181-1X; the attribute part number is 6-4-7181X — both refer to this unit.
Additional information
| Cj to end | 5.391 |
|---|---|
| Hub dia | 3.250″ |
| Partn number | 6-4-7181X |
| Series | 1710 |
| Splines count | 46 |
| Splines dia | 2.390″ |
| Style | BP |
| Through hole | 2.328 |
