4126-506A – Weld Yokes – 1410 Series – Butt Dia 4.757″ – Tube Dia Wall 5.000X0.125
$75.43
13 People watching this product now!
Description
4126-506A weld yoke — Aluminum, 1410 series. fits 5.000X0.125 tube | 4.757″ butt dia | 3.000″” center-to-weld. Verify tube OD before ordering.
Full Description
The 4126-506A weld yoke dimensions: butt diameter matches tube OD, center-to-weld determines your working driveshaft length. Both matter.
4126-506A Weld Yoke -- Dimensions & Fitment
The 1410 series is the standard for HD trucks -- F-250/350/450, Ram 2500/3500, Dana 60/70 axles. 4126-506A weld yoke -- fits 5.000X0.125 tube | 4.757" butt dia | 3.000"" center-to-weld.
Aluminum T6061 construction -- lighter rotating mass reduces driveline stress. Tack in place before final weld -- confirm runout is within 0.005" before committing to full weld.
Key Features
- Series: 1410 -- HD trucks -- F-250/350/450, Ram 2500/3500, Dana 60/70 axles
- Tube fit: 5.000X0.125 -- butt diameter machined to this tube OD only
- Butt diameter: 4.757" -- slides over tube OD for weld prep
- Center-to-weld: 3.000"" -- factors into overall driveshaft length calculation
- Aluminum T6061 -- roughly 60% lighter than steel equivalent, corrosion resistant
Specifications
- SKU: 4126-506A
- Brand: UDS
- Series: 1410
- Material: Aluminum
- Tube Dia x Wall: 5.000X0.125
- Butt Dia: 4.757"
- Center UJ to Weld: 3.000""
Additional information
| Butt dia | 4.757 |
|---|---|
| Center u j to weld | 3.000" |
| Material | ALUMINUM |
| Partn number | 4126-506A |
| Series | 1410 |
| Tube dia wall | 5.000X0.125 |
| Brand | UDS |
