3-4-1501-1 End Yoke – Splined Bore 1350 Series, Strap Style, 1.500×10 Spline, 2.250 Hub
$61.20
+50 in stock
15
People watching this product now!
Description
3-4-1501-1 end yoke, 1350 series strap style, 1.500″x10 spline, 2.250″ hub dia, 3.530″ CJ-to-end, 2.063″ through-hole. Verify spline count before ordering.
Full Description
3-4-1501-1 End Yoke 1350 Series Strap Style 1.500x10 Spline 2.250 Hub
The 3-4-1501-1 is a 1350 series strap-style (BS) end yoke with a 1.500" spline diameter and 10-spline bore. The hub diameter is 2.250", the CJ to end dimension is 3.530", and the through-hole is 2.063". Among the 1350 series strap yoke variants, the 3-4-1501-1 has the shortest CJ-to-end (3.530") and a 2.063" through-hole, distinguishing it from the 3-4-1441-1 (2.000" through-hole) which shares the same hub and spline spec.
Specifications
- Part Number: 3-4-1501-1
- Series: 1350
- Style: BS (Strap)
- Spline Diameter: 1.500"
- Spline Count: 10
- Hub Diameter: 2.250"
- CJ to End: 3.530"
- Through Hole: 2.063"
When fitting the 3-4-1501-1, verify the output shaft has 10 splines at 1.500" diameter. The 2.063" through-hole is larger than the 2.000" through-hole on the 3-4-1441-1 — this distinction matters if a retaining bolt or nut passes through the bore. The 3.530" CJ-to-end is the shortest in this 1350 strap yoke family, making it appropriate where a compact end-yoke installation length is required.
The 3-4-1501-1 is strap-retention style; U-joints for this yoke must be strap-compatible in 1350 series. When selecting among the 1350 series 1.500"x10 strap yokes (3-4-2231-1, 3-4-8511-1, 3-4-13881-1, 3-4-1501-1, 3-4-1441-1), use CJ-to-end length and through-hole diameter to differentiate. Verify spline count and diameter before ordering.
Additional information
| Cj to end | 3.530 |
|---|---|
| Hub dia | 2.250 |
| Partn number | 3-4-1501-1 |
| Series | 1350 |
| Splines count | 10 |
| Splines dia | 1.500″ |
| Style | BS |
| Through hole | 2.063 |
