2903-301 – Transmission Yokes – 7290 Series – 29/30 X 1.312 Splines – 1.681″ Hub Dia
$87.74
15
People watching this product now!
Description
2903-301 Transmission Yoke — 7290 series, 29/30 X 1.312 spline | 1.681″ hub | 8.031″ CJ-to-end. Full Spline.. Proven direct replacement.
Full Description
The 2903-301 transmission yoke is the connection between the gearbox tailshaft and the front of the driveshaft. It splines onto the transmission output shaft and carries the front u-joint of the driveshaft. For 7290 series applications, the spline count and hub diameter are the two specs that determine whether this part fits your tailshaft correctly.
2903-301 Transmission Yoke — 7290 Series Specs & Tailshaft Fit
The 2903-301 transmission yoke specs: 29/30 X 1.312 spline | 1.681" hub | 8.031" CJ-to-end. Compatible with: Full Spline.. Hub diameter determines engagement depth on the tailshaft — if the hub is too short, the splines don't fully engage. CJ-to-end affects driveshaft working length.
After a transmission rebuild or swap, confirm the tailshaft spline count hasn't changed before installing the 2903-301 transmission yoke. Not all 7290 series transmissions use the same output spline across all years and configurations. Count the splines on the actual shaft.
Key Features
- Series: 7290 — application-specific
- Spline: 29/30 X 1.312 — must match transmission tailshaft
- Hub dia: 1.681" — determines spline engagement depth
- CJ-to-end: 8.031" — affects driveshaft working length
- Compatible with: Full Spline.
- Brand: UDS
Specifications
- SKU: 2903-301
- Brand: UDS
- Series: 7290
- Spline: 29/30 X 1.312
- Hub Dia: 1.681"
- CJ to End: 8.031"
- Notes: Full Spline.
Additional information
| Center u joint to end |
8.031 |
|---|---|
| Counter bore dia |
0 |
| Hub dia |
1.681 |
| Notes |
Full Spline. |
| Partn number |
2903-301 |
| Series |
7290 |
| Splines count dia |
29/30 X 1.312 |
