2826-4120 – Tri & Quad Prongs – Bolt Circle Dia 120MM – Bolt Hole Dia 12MM – Butt Dia 2.344

The 2826-4120 is a quad-prong (four-prong) weld yoke rather than a tri-prong, as indicated by the QUAD PRONG note in the catalog data. Quad-prong yokes use four prongs instead of three, which distributes load over more contact points and generally allows higher torque transmission through the joint interface. This variant serves the Mercedes-Benz 120mm bolt circle application.

The 120mm bolt circle on a Mercedes application is larger than the 90mm used on most Mercedes passenger car prong yokes, suggesting this serves a larger Mercedes vehicle - likely a Sprinter van, G-Class, or heavy-duty derivative.

Do not confuse tri-prong and quad-prong yokes. The count of prongs must match the mating component. If your differential flange has four sockets, you need a quad-prong. If three, a tri-prong. This distinction cannot be corrected with adaptation. Compare with 2826-110 and 2826-4110 for the 110mm Mercedes variants.
