2-3-14031X Transmission Slip Yoke..1330 series, 1.284×30 spline, 1.680 Ground Hub Diameter
$41.44
1 in stock
17
People watching this product now!
Description
2-3-14031X nickel-plated 1330 series slip yoke for Chrysler/Dodge 46RH, 46RE, 47RE, 47RH, 48RE, A518, 45RFE transmissions. 29/30 splines at 1.284″, 8.030″ CJ-to-end, 1.440″ counterbore, 1.681″ hub. Cross-ref: PTI 3303-301. Not compatible with A727 TorqueFlite.
Full Description
2-3-14031X -- Nickel-Plated 1330 Slip Yoke for Chrysler 46RE / 47RE / A518, 30-Spline
Nickel plating is not cosmetic on this yoke -- it provides corrosion protection in the spline bore where condensation, road spray, and fluid contamination accumulate over the yoke's service life. The 2-3-14031X fits the Chrysler/Dodge 46RH, 46RE, 47RE, 47RH, 48RE, A518/518, 45RFE, 545RFE, and 65RFE transmissions. Cross-reference: PTI 3303-301.
Important fitment note: This yoke does NOT fit the A727 TorqueFlite despite what some listings suggest. The 727 uses a different spline count. The 29/30 spline designation means the outer spline count is 30, with one blind spline producing 29 visible teeth -- a Chrysler production convention. Confirm your transmission is in the 46RE/47RE/A518 family before ordering.
| Part Number | 2-3-14031X | PTI 3303-301 |
| Series | 1330 |
| Finish | Nickel plated |
| Splines | 29/30 x 1.284" diameter |
| CJ to End | 8.030" |
| Counterbore | 1.440" |
| Hub Dia | 1.681" |
| Fits | 46RH/RE, 47RH/RE, 48RE, A518, 45RFE, 545RFE, 65RFE |
| Does NOT fit | A727 TorqueFlite |
All Chrysler/Dodge transmission Slip Yokes in stock including 1330, 1350, and heavy-duty series.
Additional information
| Center u joint to end | 8.030 |
|---|---|
| Counter bore dia | 1.440 |
| Hub dia | 1.681 |
| Notes | Nickel plated, Chrysler 46RH/46RE/47RE/727/A518 trans |
| Partn number | 2-3-14031X |
| Series | 1330 |
| Splines count dia | 29/30 1.284 |
