2-28-427 Weld Tube Yoke 1310 Ser’ , Fits: 3.000 X 0.083 , CL To Weld: 1.688 Inch Butt Dia: 3.344
$16.97
+50 in stock
Description
2-28-427: 1310 steel weld yoke, 3.500×0.083 tube, butt 3.344″ — 3.5″ tube provides additional torsional stiffness; check that 1310 series is adequate for peak torque before specifying over a 1330 yoke.
Full Description
A common engineering trade-off: using a larger-diameter tube with a lower-rated U-joint series. The 2-28-427 pairs a 3.500" OD tube -- which provides excellent torsional rigidity and high critical speed -- with a 1310-series U-joint interface that is rated lower than the 1330 or 1350. In applications where the tube is the primary structural element and peak torque is below the 1310-series limit (approximately 1,200 ft-lb), this is a valid choice. However, if peak torque is a concern, swap to the 3326-427 (1330-series) or 3556-427 (1350-series) equivalent weld yoke at the same tube size.
- Series: 1310 -- 1.062" cap diameter
- Tube: 3.500" OD x 0.083" wall steel
- Butt diameter: 3.344"
- Center U-joint to weld: 1.688"
- Critical speed of 3.5" x 0.083" x 40" shaft: approximately 6,800 RPM
Tip: for this weld yoke, confirm phasing -- both yokes on a single-piece shaft must be in phase (0 degrees) unless the shaft operates at a constant working angle where out-of-phase is specified.
Additional information
| Butt dia | 3.344 |
|---|---|
| Center u j to weld | 1.688 |
| Material | STEEL |
| Partn number | 2-28-427 |
| Series | 1310 |
| Tube dia wall | 3.500X0.083 |
| Brand | UDS |
