Brand:
5503-318 Transmission Slip Yoke, Fits 1550 Series – 30/31 Splines x 1.610 Spline Dia 40189967
$119.81
3 in stock
20 People watching this product now!
Description
5503-318 Transmission Yoke — 1550 series, 30/31 x 1.610 spline | 2.201″ hub | 9.750″ CJ-to-end. 68RFE 2wd; Chrysler, Dodge, and GM Vehicles. Proven direct replacement.
Full Description
The 5503-318 transmission yoke is the connection between the gearbox tailshaft and the front of the driveshaft. It splines onto the transmission output shaft and carries the front u-joint of the driveshaft. For 1550 series applications, the spline count and hub diameter are the two specs that determine whether this part fits your tailshaft correctly.
5503-318 Transmission Yoke — 1550 Series Specs & Tailshaft Fit
The 1550 series covers commercial fleet Class 5-6 and medium-duty vocational trucks. The 5503-318 transmission yoke specs: 30/31 x 1.610 spline | 2.201" hub | 9.750" CJ-to-end. Compatible with: 68RFE 2wd; Chrysler, Dodge, and GM Vehicles. Hub diameter determines engagement depth on the tailshaft — if the hub is too short, the splines don't fully engage. CJ-to-end affects driveshaft working length.
After a transmission rebuild or swap, confirm the tailshaft spline count hasn't changed before installing the 5503-318 transmission yoke. Not all 1550 series transmissions use the same output spline across all years and configurations. Count the splines on the actual shaft.
Key Features
- Series: 1550 — commercial fleet Class 5-6 and medium-duty vocational trucks
- Spline: 30/31 x 1.610 — must match transmission tailshaft
- Hub dia: 2.201" — determines spline engagement depth
- CJ-to-end: 9.750" — affects driveshaft working length
- Compatible with: 68RFE 2wd; Chrysler, Dodge, and GM Vehicles
- Brand: UDS
Specifications
- SKU: 5503-318
- Brand: UDS
- Series: 1550
- Spline: 30/31 x 1.610
- Hub Dia: 2.201"
- CJ to End: 9.750"
- Notes: 68RFE 2wd; Chrysler, Dodge, and GM Vehicles
Additional information
| Center u joint to end | 9.750 |
|---|---|
| Counter bore dia | 0 |
| Hub dia | 2.201 |
| Notes | 68RFE 2wd ,Chrysler, Dodge, and GM Vehicles |
| Partn number | 5503-318 |
| Series | 1550 |
| Splines count dia | 30/31 x 1.610 |
| Brand | UDS |
