Brand:
5-3200X Universal Joint 22X54 OSR 0.866×2.126 Neapco PN: 1-0121 PTO Metric B&P Series 1 BONDIOLI & PAVESI
$12.83
29 in stock
Description
5-3200X universal joint cross, SERIES 1 series, 0.866″ cap diameter — replacement u-joint for BONDIOLI & PAVESI applications.
Full Description
5-3200X Universal Joint -- SERIES 1 Series
The 5-3200X is a SERIES 1 series universal joint cross designed for SERIES 1 series driveshaft applications. Cap diameter is 0.866" with an overall width of 2.126". This cross is greaseable (zerk fitting included).
Dimensional Specifications
| Parameter | Value |
|---|---|
| Part Number | 5-3200X |
| Series | SERIES 1 |
| Style | OSR |
| Cap Diameter | 0.866" |
| Width (across caps) | 2.126" |
| Lubrication | greaseable (zerk fitting included) |
| Brand | UDS |
| Notes | BONDIOLI & PAVESI |
Series & Compatibility
The SERIES 1 series uses a 0.866" cap diameter. All four cap sockets must be SERIES 1 series yoke bores -- mixing series at a single joint creates uneven bearing loads and will cause premature cap failure. Confirm the series designation on both yokes before installing this cross.
Lubrication & Maintenance
This cross is greaseable (zerk fitting included). Grease at every oil change interval with NLGI 2 extreme-pressure grease. Purge until fresh grease appears at each seal -- this also flushes contaminants from the bearing races.
Installation Notes
- Clean all four cap bores in the yoke ears before pressing in the new caps.
- Press caps squarely -- do not cock the cap during installation or the needle rollers will skew.
- Install all snap rings and confirm seating before applying full torque to the driveshaft.
- Check for binding through the full operating angle range after installation.
BONDIOLI & PAVESI
New to U-joints? See our universal joint guide for styles, snap-ring types, and measuring tips.
Additional information
| Series | SERIES 1 |
|---|---|
| Style | OSR |
| Cap dia 1 | 0.866 |
| Width 1 | 2.126 |
| Lube | Yes |
| Brand | UDS |
| Notes | BONDIOLI & PAVESI, PTO Metric B&P Series 1 |
