200-7906 UDS Cross Bearing Kit 32×106|36×89 Combo U-joint
$80.82
50 in stock
18
People watching this product now!
Description
200-7906 UDS cross bearing kit, combo U-joint OSR style. Cap dia 1: 1.410″ x 4.160″ wide. Cap dia 2: 1.260″ x 3.500″ wide. 32x36x89x106mm. Verify both yoke cap bores before ordering.
Full Description
200-7906 UDS Cross Bearing Kit Combo U-Joint 32x106 / 36x89
The 200-7906 is a UDS cross and bearing kit in a combo U-joint configuration. This OSR (outside snap ring) style kit bridges two different cap diameters in a single assembly: cap diameter 1 is 1.410" with a width of 4.160", and cap diameter 2 is 1.260" with a width of 3.500". The kit measures 32mm x 36mm x 89.0mm x 106mm across its four trunnion positions, accommodating mismatched yoke series at opposite ends of the joint.
Specifications
- Part Number: 200-7906
- Brand: UDS
- Style: OSR (Outside Snap Ring)
- Cap Dia 1: 1.410"
- Width 1: 4.160"
- Cap Dia 2: 1.260"
- Width 2: 3.500"
- Lube: Cap Lube
- Notes: Cross and Bearing Kit — 32mm x 36mm x 89.0mm x 106mm
When fitting the 200-7906, confirm that the yoke at the 1.410" cap-diameter end accepts 4.160" wide caps, and the yoke at the 1.260" cap-diameter end accepts 3.500" wide caps. Combo U-joints are used specifically where two driveshaft series of different ratings connect — verify both yoke cap bore diameters and snap ring groove depths before assembly. Lubrication is cap-applied.
The 200-7906 is an OSR style kit, meaning snap rings seat on the outside of the yoke ears. Confirm yoke ear thickness and snap ring groove dimensions on both mating yokes before ordering. The combo cross configuration of the 200-7906 makes it non-interchangeable with standard single-diameter U-joints in either the 1.410" or 1.260" cap series.
Additional information
| Brand | UDS |
|---|---|
| Cap dia 1 | 1.410 |
| Cap dia 2 | 1.260 |
| Width 1 | 3.500 |
| Width 2 | 4.160 |
| Lube | CAP LUBE |
| Style | OSR |
| Notes | Cross and Bearing Kit. 32 mm x 36 mm x 89.0 mm x 106 mm |
| Partn number | 200-7906 |
