2-2276 UDS U Joint 1340 Series OSR 35N
$11.99
44 in stock
11 People watching this product now!
Description
2-2276 — 1340 series, 1.250″ cap, 3.207″ width. Genuine greaseable universal joint. Verify cap dia and snap ring style before ordering.
Full Description
The 2-2276 is a 1340 series outside snap ring retention universal joint measuring 1.250" cap dia | 3.207" width. The 2-2276 is greaseable with zerk fitting. Every 2-2276 is verified for cap diameter, bearing width, and snap ring groove dimensions before it ships from Universal Driveshafts.
2-2276 -- 1340 Series Cap & Width Specifications
The this u-joint specs: 1.250" cap dia | 3.207" width. Cap diameter determines which yoke bore it fits -- the cap must seat fully into the yoke without play. Bearing width (3.207" across the body) controls the span between yoke ears. A cross that is too wide won't fit; too narrow and the snap rings don't seat in the groove. 5-243X 35N series.
Verify the yoke bore diameter against the it cap size before installing. The snap ring style (outside snap ring retention) must match the yoke groove pattern -- OSR yokes have an external groove; ISR yokes have an internal groove. The this unit requires a grease gun at installation and at regular service intervals. Correct installation torque on the strap kit or U-bolt is critical -- undertorqued straps allow the cap to walk under load.
Installation Notes for the assembly
Before installing the this u-joint, clean the yoke bores of any rust, burrs, or old bearing material. The bearing cups must drop in by hand -- never drive them in with a hammer directly on the cup. Use a proper cross-and-bearing installation tool or a press. Driving a cup in at an angle cocks the needle bearings and destroys the it before it ever sees load.
After installation, verify full rotation without binding. A binding cross indicates a cup is cocked or seated too deep. The the part should articulate freely through the full operating angle of your driveshaft before the vehicle is lowered off the lift.
Key Features
- Series: 1340 series
- Cap dia: 1.250" -- must match yoke bore exactly
- Width: 3.207" -- controls yoke ear span
- Style: outside snap ring retention -- verify yoke groove type before ordering
- Greaseable -- zerk fitting included, service at regular intervals
- Brand: UDS
- Note: 5-243X 35N series
Specifications
- SKU: this componentU
- Part Number: this u-joint
- Brand: UDS
- Series: 1340
- Cap Dia 1: 1.250"
- Width 1: 3.207"
- Snap Ring Style: OSR
- Lube: Yes -- grease fitting
- Notes: 5-243X 35N series
Additional information
| Brand | UDS |
|---|---|
| Cap dia 1 | 1.250 |
| Width 1 | 3.207 |
| Lube | Y |
| Style | OSR |
| Partn number | 2-2276 |
| Series | 1340 |
| Notes | 5-243X 35N series |
