3526-4120 – Tri & Quad Prongs – Bolt Circle Dia 120MM – Butt Dia 2.844″ – Face To Weld 1.634

3526-4120 Mercedes Sprinter Tri Prong – 120MM Bolt Circle – 2.844" Butt Dia – 1.634" Face to Weld

The 3526-4120 is a tri prong flange yoke for Mercedes Sprinter applications with a 120MM bolt circle diameter. The bolt holes are 12MM clearance with an 18mm pilot diameter. The butt diameter measures 2.844" and the face-to-weld length is 1.634". The nose bushing diameter is 31MM. This unit welds to a 3.000" x 0.083" tube.

Specifications

• Part Number: 3526-4120
• Application: Mercedes Sprinter
• Bolt Circle Dia: 120MM
• Bolt Hole Dia: 12MM
• Bolt Hole Pilot Dia: 18mm
• Nose Bushing Dia: 31MM
• Butt Dia: 2.844"
• Face to Weld: 1.634"
• Tube Dia x Wall: 3.000" x 0.083"

When fitting the 3526-4120 on a Mercedes Sprinter, confirm the driveshaft tube is 3.000" OD with 0.083" wall before welding. The 12MM clearance bolt holes and 18mm pilot diameter must match the Mercedes Sprinter companion flange. The 3.000" tube spec is consistent with the commercial van driveshaft diameter. The 3526-4120 and 3526-4121 (Dodge Sprinter) share the 120MM bolt circle, 2.844" butt, and 3.000" tube. The key differences: 3526-4120 uses 12MM clearance holes (1.634" FTW) versus 3526-4121 threaded 12x1.5 (1.638" FTW). Confirm the Mercedes Sprinter requires clearance bolt holes and the 1.634" face-to-weld before ordering.
