SA54-25-300 Center Support Bearing Ford Ranger / Courier 4X4 Bearing ID: 35mm
$35.80
27 in stock
13
People watching this product now!
Description
SA54-25-300 center support bearing for Ford Ranger / Courier 4×4. Bearing ID 1.378 in (35 mm), 6.875 in hole spacing, 2.565 in center-to-base. Verify ID and mount spacing before ordering.
Full Description
SA54-25-300 Center Support Bearing — Ford Ranger / Courier 4x4
The SA54-25-300 is a center support bearing for the Ford Ranger and Courier 4x4 applications. The bearing ID is 1.378 inches (35 mm), the center-to-center of mounting holes is 6.875 inches, and the center-bearing-to-base dimension is 2.565 inches. This bearing presses into the bracket assembly and supports the midshaft stub on the two-piece driveshaft used in these 4x4 trucks.
Specifications
- Part Number: SA54-25-300
- Application: Mazda / Ford (Ford Ranger / Courier 4x4)
- Bearing ID: 1.378 in (35 mm)
- Center Bearing to Base: 2.565 in
- Center-to-Center Mount Holes: 6.875 in
When installing the SA54-25-300, confirm the midshaft stub OD is 1.378 inches (35 mm). The 6.875-inch mounting hole spacing must match the crossmember pattern on the Ford Ranger or Courier 4x4 platform. The 2.565-inch center-to-base offset determines the midshaft centerline height relative to the mounting face.
The SA54-25-300 uses a 35 mm ID bearing, which is larger than the 28 mm ID used in the SA54-25-28 series. These two bearings are not interchangeable — ordering the wrong ID will result in either a loose fit or a bearing that cannot be installed on the midshaft. Verify bearing ID and mount spacing before ordering.
Additional information
| Application | Mazda / Ford |
|---|---|
| Bearing id | 1.378 |
| Center bearing to base | 2.565 |
| Ctr to ctr of mount holes | 6.875 |
| Partn number | SA54-25-300 |
