SA54-25-28 Center Support Bearing Ford Mazda Kia ID: 28mm | 1.102 Bearing ID
$31.80
27 in stock
11
People watching this product now!
Description
SA54-25-28 center support bearing for Mazda and Ford. Bearing ID 1.102 in (28 mm), 7.000 in hole spacing, 2.565 in center-to-base. Verify ID and mount spacing before ordering.
Full Description
SA54-25-28 Center Support Bearing — Mazda / Ford
The SA54-25-28 is a center support bearing for Mazda and Ford applications. The bearing ID is 1.102 inches (28 mm), the center-to-center of mounting holes is 7.000 inches, and the center-bearing-to-base dimension is 2.565 inches. This bearing supports the midshaft of a two-piece driveshaft, pressing into the bracket that bolts to the vehicle frame or crossmember.
Specifications
- Part Number: SA54-25-28
- Application: Mazda / Ford
- Bearing ID: 1.102 in (28 mm)
- Center Bearing to Base: 2.565 in
- Center-to-Center Mount Holes: 7.000 in
When installing the SA54-25-28, confirm the midshaft stub OD is 1.102 inches (28 mm). The 7.000-inch mounting hole spacing must align with the crossmember pattern on the Mazda or Ford application. The 2.565-inch center-to-base offset determines the vertical positioning of the midshaft centerline relative to the mounting flange.
The SA54-25-28 is dimensionally close to the SA54-25-28B, which shares the same ID and hole spacing but has a larger center-to-base measurement of 2.750 inches. If your application requires the additional offset height, order the SA54-25-28B instead. Verify bearing ID and mount spacing before ordering.
Additional information
| Application | Mazda / Ford |
|---|---|
| Bearing id | 1.102 |
| Center bearing to base | 2.565 |
| Ctr to ctr of mount holes | 7.000 |
| Partn number | SA54-25-28 |
