Brand:
Center Support Bearing CBFGM-55 for Mercedes / Isuzu – Bearing Internal Diameter: 2.362 , Mounting Holes 11.750, C/L To Base 4.000
$107.86
26 in stock
19
People watching this product now!
Description
CBFGM-55 UDS center support bearing for Mercedes and Isuzu European trucks. Bearing ID 2.362 in, 11.750 in hole spacing, 4.000 in center-to-base. Verify ID and mount spacing before ordering.
Full Description
CBFGM-55 UDS Center Support Bearing — Mercedes / Isuzu European Trucks
The CBFGM-55 is a UDS center support bearing for Mercedes and Isuzu applications, designed for multiple European trucks. The bearing ID is 2.362 inches, the center-to-center of mounting holes is 11.750 inches, and the center-bearing-to-base is 4.000 inches. This bearing serves the midshaft on large commercial vehicle two-piece driveshafts in the European heavy-truck segment.
Specifications
- Part Number: CBFGM-55
- Brand: UDS
- Application: Mercedes / Isuzu European Trucks
- Bearing ID: 2.362 in
- Center Bearing to Base: 4.000 in
- Center-to-Center Mount Holes: 11.750 in
- Note: Fits multiple European trucks
When installing the CBFGM-55, confirm the midshaft stub OD is 2.362 inches. The 11.750-inch mounting hole spacing corresponds to the wide crossmember geometry on European heavy commercial trucks. The 4.000-inch center-to-base offset must match the vehicle's OEM midshaft height at the crossmember mounting location.
The CBFGM-55 uses a 2.362-inch bearing ID, which is larger than the CBGM-60 (2.165 in ID). Despite sharing identical hole spacing and center-to-base dimensions, these two bearings fit different midshaft stub diameters and are not interchangeable. Confirm the stub OD against the bearing ID before ordering. Verify ID and mount spacing before installation.
Additional information
| Bearing id | 2.362 |
|---|---|
| Ctr to ctr of mount holes | 11.750 |
| Center bearing to base | 4.000 |
| Application | Mercedes / Isuzu |
| Brand | UDS |
| Notes | Fits multiple European trucks |
