3580-47 Center Support Bearing 25-141739X Bearing ID: 47×21 1.850 x 0.827 Mounting Holes: 7.620 Dodge / Mercedes Sprinter Vans CBMS4721196 , N214734
$54.36
+50 in stock
18
People watching this product now!
Description
3580-47 center support bearing for Dodge/Mercedes Sprinter vans (25-141739X, CBMS4721196, N214734). Bearing ID 1.850 in (47×21 mm), 7.625 in hole spacing. Verify ID before ordering.
Full Description
3580-47 Center Support Bearing — Dodge / Mercedes Sprinter Vans
The 3580-47 is a center support bearing for Dodge and Mercedes Sprinter vans, cross-referencing to part numbers 25-141739X, CBMS4721196, and N214734. The bearing ID is 1.850 inches (47 x 21 mm), the center-to-center of mounting holes is 7.625 inches, and the center-bearing-to-base is 2.700 inches.
Specifications
- Part Number: 3580-47
- Application: Dodge / Mercedes Sprinter Vans
- Cross-Reference: 25-141739X, CBMS4721196, N214734
- Bearing ID: 1.850 in (47 x 21 mm)
- Center Bearing to Base: 2.700 in
- Center-to-Center Mount Holes: 7.625 in
When installing the 3580-47, confirm the midshaft stub OD is 1.850 inches (47 mm). The 7.625-inch mounting hole spacing must align with the Sprinter van crossmember bolt pattern. The 2.700-inch center-to-base dimension sets the midshaft height at the crossmember location; this must match the OEM geometry on the Dodge/Mercedes Sprinter platform.
The 3580-47 bearing assembly uses a 47 x 21 mm bearing, which corresponds to the metric specification used in Sprinter van driveshaft systems. Cross-references 25-141739X, CBMS4721196, and N214734 can be used to confirm fitment against Sprinter parts databases. Verify bearing ID and mount spacing before installation.
Additional information
| Application | Sprinters Van |
|---|---|
| Bearing id | 1.850 |
| Center bearing to base | 2.700 |
| Ctr to ctr of mount holes | 7.625 |
| Notes | Dodge/Mercedes Sprinter Vans |
| Partn number | 3580-47 |
