3-28-97U – Weld Yokes – 1410 Series – Butt Dia 2.344″ – Tube Dia Wall 3.000X0.095
$50.21
17
People watching this product now!
Description
Weld yoke 3-28-97U, 1410. fits 3.000X0.095 tube | 2.344″ butt dia | 2.125″ center-to-weld. Tube OD must match butt diameter.
Full Description
Balance starts at the weld. The 3-28-97U weld yoke is machined concentric so the driveshaft doesn't introduce runout at the joint after welding.
3-28-97U Weld Yoke -- Dimensions & Fitment
The 1410 series is the standard for HD trucks -- F-250/350/450, Ram 2500/3500, Dana 60/70 axles. 3-28-97U weld yoke -- fits 3.000X0.095 tube | 2.344" butt dia | 2.125" center-to-weld.
Steel DOM-compatible -- standard weld prep, full-penetration weld recommended. Tack in place before final weld -- confirm runout is within 0.005" before committing to full weld.
Key Features
- Series: 1410 -- HD trucks -- F-250/350/450, Ram 2500/3500, Dana 60/70 axles
- Tube fit: 3.000X0.095 -- butt diameter machined to this tube OD only
- Butt diameter: 2.344" -- slides over tube OD for weld prep
- Center-to-weld: 2.125" -- factors into overall driveshaft length calculation
- Steel construction -- standard weld-compatible material
- Spicer-built -- OEM supplier, forged not cast
Specifications
- SKU: 3-28-97U
- Brand: SPICER
- Series: 1410
- Material: Steel
- Tube Dia x Wall: 3.000X0.095
- Butt Dia: 2.344"
- Center UJ to Weld: 2.125"
Additional information
| Butt dia |
2.344 |
|---|---|
| Center u j to weld |
2.125 |
| Material |
STEEL |
| Partn number |
3-28-97U |
| Series |
1410 |
| Tube dia wall |
3.000X0.095 |
| Brand |
SPICER |
