3-28-3281 Ball Stud Yoke – 1350 Series Fits Tube: 2.500 x 0.095
$46.23
28 in stock
17
People watching this product now!
Description
3-28-3281 UDS 1350 series ball stud yoke for 2.500 x 0.095 tube. Butt dia 2.321″, CJ-to-weld 1.730″, ball stud 0.600×0.500″, includes rubber dust cover.
Full Description
3-28-3281 UDS 1350 Series Ball Stud Yoke – Fits 2.500 x 0.095 Tube
The 3-28-3281 is a UDS 1350 series ball stud yoke designed to weld onto 2.500" OD x 0.095" wall driveshaft tubing. The butt diameter is 2.321" and the center U-joint to weld dimension is 1.730". Ball stud dimensions are 0.600" length by 0.500" diameter. A rubber dust cover is included.
Specifications
- Part Number: 3-28-3281 (ref: 3R26-20)
- Brand: UDS
- Series: 1350
- Tube OD x Wall: 2.500" x 0.095"
- Butt Diameter: 2.321"
- Center U-Joint to Weld: 1.730"
- Ball Stud Length x Diameter: 0.600" x 0.500"
- Notes: Includes rubber dust cover
When fitting the 3-28-3281, confirm tube OD is exactly 2.500" and wall thickness is 0.095" before welding. The butt diameter of 2.321" sets the insert depth into the tube end. The 1350 series U-joint ears must match the mating yoke at the opposite shaft end. The center U-joint to weld measurement of 1.730" is critical for maintaining correct driveshaft working length after assembly.
The rubber dust cover supplied with the 3-28-3281 protects the ball stud socket from contamination. Verify the mating CV socket or slip assembly ball stud bore matches the 0.500" ball diameter spec before installation.
Additional information
| Ball stud length dia | 0.600×0.500 |
|---|---|
| Butt dia | 2.321 |
| Center u j to weld | 1.730 |
| Notes | DUST COVER RUBBER |
| Partn number | 3R26-20 |
| Series | 1350 |
| Tube dia wall | 2.500X0.095 |
| Brand | UDS |
