1426-862 – Weld Yokes – CVJ Series – Butt Dia 2.375″ – Tube Dia Wall 2.500X0.065
$85.33
20
People watching this product now!
Description
1426-862 Weld Yoke — Steel, CVJ series, fits 2.500X0.065 tube | 2.375″ butt dia | 1.250″” center-to-weld. Premium weld-on replacement. Match tube OD before ordering.
Full Description
The 1426-862 weld yoke is a steel weld-on yoke for CVJ series driveshaft applications. It attaches permanently to the tube via weld and carries the u-joint cross at the outboard end of the shaft. Center-to-weld dimension and butt diameter are the two numbers that matter most here.
1426-862 Weld Yoke — Tube Fit & Steel Specs
The 1426-862 weld yoke specs: fits 2.500X0.065 tube | 2.375" butt dia | 1.250"" center-to-weld. USED WITH: 1452-8602-8602 AND 1453-860 M8-1.25. Steel construction — DOM-compatible, full-penetration weld ready, standard for high-torque driveshaft applications. Center-to-weld dimension is critical for total shaft length calculations — it's the distance consumed by this yoke on that end of the tube.
Measure your tube OD before cutting and welding the 1426-862 weld yoke. Tack it in place first, check runout is within 0.005" before committing to full weld. A slight off-angle tack that gets welded solid will show up as vibration at 50+ mph that no balancer can fully correct.
Key Features
- Series: CVJ — application-specific
- Tube fit: 2.500X0.065 — butt diameter is machined specifically for this OD
- Butt dia: 2.375" — must match tube OD precisely for a centered weld joint
- Center-to-weld: 1.250"" — factors into total shaft length calculation
- Steel — DOM-compatible, full-penetration weld, standard drivetrain spec
- Brand: UDS
- Note: USED WITH: 1452-8602-8602 AND 1453-860 M8-1.25
Specifications
- SKU: 1426-862
- Brand: UDS
- Series: CVJ
- Material: Steel
- Tube Fit: 2.500X0.065
- Butt Dia: 2.375"
- Center to Weld: 1.250""
- Notes: USED WITH: 1452-8602-8602 AND 1453-860 M8-1.25
Additional information
| Butt dia |
2.375 |
|---|---|
| Center u j to weld |
1.250" |
| Material |
STEEL |
| Notes |
USED WITH: 1452-8602-8602 AND 1453-860 M8-1.25 |
| Partn number |
1426-862 |
| Series |
CVJ |
| Tube dia wall |
2.500X0.065 |
| Brand |
UDS |
