Brand:
SA68740-346 Driveshaft Slip Yoke 68740/2040 Series Slip Joint , Center Line To Weld: 346mm, Tube: 100×3.875 Butt Diameter: 92.25
$230.67
13 in stock
17 People watching this product now!
Description
SA68740-346 UDS 687.40 series slip yoke. Splines: 34, CJ-to-end: “. Verify stop shaft spline count and diameter before ordering.
Full Description
SA68740-346 UDS 687.40 Slip Yoke
The SA68740-346 is a 687.40 series slip yoke manufactured by UDS. The slip yoke slides over the stop shaft — the splined stub welded onto the front section of the driveshaft tube — and telescopes in and out as the suspension cycles. This allows the driveshaft to change working length without binding.
The spline specification is 34; verify this matches the stop shaft before ordering. Driveshaft Slip Yoke 47.6x135 / 2040 Fits: 100x3.875. The 687.40 series is designed for the specified application range.
Specifications
- Part Number: SA68740-346
- Brand: UDS
- Series: 687.40
- Butt dia: 92.25
- Material: STEEL
- Notes: Driveshaft Slip Yoke 47.6x135 / 2040 Fits: 100x3.875
- Splines count: 34
- Splines dia: 61.10mm
- Fits to tube: 100x3.875
Fitment & Installation Notes
When selecting the SA68740-346, verify the stop shaft spline count and diameter match the 34 specification. Inspect the stop shaft for wear or damage; a worn shaft will produce lash even with a new yoke.
View the full range of Slip Assemblies in 687.40 and adjacent series configurations.
Additional information
| Butt dia | 92.25 |
|---|---|
| Material | STEEL |
| Notes | Driveshaft Slip Yoke 47.6×135 / 2040 Fits: 100×3.875 |
| Partn number | SA68740-346 |
| Series | 687.40 |
| Brand | UDS |
| Splines count | 34 |
| Splines dia | 61.10mm |
| Fits to tube | 100×3.875 |
