CBITLD Carrier Bearing ISUZU Truck Isuzu ELF 250TLD
$36.26
33 in stock
19 People watching this product now!
Description
Cbitld Center Support Bearing — Isuzu series, 1.260″ inner dia | 2.750″ center-to-base | 6.250″ mount spacing. Complete replacement. Verify inner dia and mount spacing.
Full Description
The CBITLD center support bearing supports the midshaft section of a two-piece driveshaft, keeping it running concentric with the vehicle's drivetrain axis. When this bearing fails, the midshaft droops and the driveshaft angles change — you'll feel it as a vibration that gets progressively worse at highway speed. The CBITLD center support bearing is the correct replacement for Isuzu series applications, with the exact inner diameter and mount hole spacing your application requires.
Cbitld Center Support Bearing — Isuzu Series Dimensions & Mount Specs
The CBITLD center support bearing specs: 1.260" inner dia | 2.750" center-to-base | 6.250" mount spacing. ISUZU 32 MM Bearing ID. Application: Isuzu series. Inner diameter must match the midshaft stub OD exactly — a loose fit allows the bearing to walk on the shaft, which causes vibration and accelerates wear on both the bearing race and the shaft surface. Mount hole center-to-center spacing must match your crossmember bracket.
When replacing a center support bearing on a two-piece shaft, replace the complete assembly — bearing race, rubber isolator, and bracket together. A new race in an old hardened rubber mount still vibrates. The rubber isolator is what actually absorbs the midshaft movement; without it the bearing transmits every frequency directly to the frame.
Key Features
- Application: Isuzu series — verify your driveshaft series matches
- Bearing inner dia: 1.260" — must match midshaft stub OD exactly
- Center-to-base: 2.750" — height from shaft centerline to mounting surface
- Mount hole spacing: 6.250" — must match crossmember bracket exactly
- Complete assembly — bearing race, rubber isolator, and bracket as one unit
- Rubber isolator included — absorbs midshaft vibration, reduces NVH to frame
- Note: ISUZU 32 MM Bearing ID
Specifications
- SKU: CBITLD
- Brand: UDS
- Application: Isuzu Series
- Bearing ID: 1.260"
- Center to Base: 2.750"
- Mount Hole Spacing: 6.250"
- Notes: ISUZU 32 MM Bearing ID
Additional information
| Application | Isuzu |
|---|---|
| Bearing id | 1.260 |
| Center bearing to base | 2.750 |
| Ctr to ctr of mount holes | 6.250 |
| Notes | ISUZU 32 MM Bearing ID |
| Partn number | CBITLD |
