9980-45 – Center Support Bearing – Subaru Application – 985″ ID – 750″ Center Bearing To Base
$94.91
7 in stock
12
People watching this product now!
Description
9980-45 center bearing — Subaru application. Bearing ID: 0.985″. One bracket 0.75″ offset below, opposite flush. Mount spacing: 6.875″. Grommets included.
Full Description
The 9980-45 serves Subaru driveshaft applications requiring a 0.985" inner bore center bearing with an offset bracket arrangement. Subaru AWD and RWD platforms frequently use offset-mount center bearings where chassis geometry places the mounting surface at an angle relative to the driveshaft centerline.
On this unit, one bracket sits 0.75" below the bearing centerline while the opposite side mounts flush (0.00" offset). This 0.75" differential tilts the bearing slightly to align with an angled tunnel or crossmember. Rubber grommets are included in the assembly to provide vibration isolation between the steel bracket and the chassis mounting points.
- Part Number: 9980-45
- Application: Subaru
- Bearing ID: 0.985"
- Center-to-Base: 0.750" (one bracket) / flush (opposite)
- Mount Hole Spacing: 6.875"
- Includes: Grommets
Compare with 9980-40 (2.000" offset, 1.000" opposite) for different Subaru models. The grommet specification is important - some aftermarket bearings omit grommets, requiring chassis-to-bracket contact that transmits driveshaft vibration directly to the body. Confirm your mounting hole accepts the grommet OD before installation.
View all center support bearings.
Additional information
| Application | Subaru |
|---|---|
| Bearing id | 985 |
| Center bearing to base | 750 |
| Ctr to ctr of mount holes | 6.875 |
| Notes | CB mounts at an offset . one bracket sits below .75″ and the opposite side mounts even. Comes with grommets |
| Partn number | 9980-45 |
