9951-23 UDS UDS 9951-23 30mm x 54.8mm Inside clip Univer…
$10.32
49 in stock
16
People watching this product now!
Description
9951-23 — N/A series, 1.181″ cap, 2.290″ width. Proven greaseable universal joint. Verify cap dia and snap ring style before ordering.
Full Description
The 9951-23 is a N/A series inside snap ring retention universal joint measuring 1.181" cap dia | 2.290" width. The 9951-23 is greaseable with zerk fitting. Every 9951-23 is verified for cap diameter, bearing width, and snap ring groove dimensions before it ships from Universal Driveshafts.
9951-23 -- N/A Series Cap & Width Specifications
The 9951-23 specs: 1.181" cap dia | 2.290" width. Cap diameter determines which yoke bore it fits -- the cap must seat fully into the yoke without play. Bearing width (2.290" across the body) controls the span between yoke ears. A cross that is too wide won't fit; too narrow and the snap rings don't seat in the groove.
Verify the yoke bore diameter against the 9951-23 cap size before installing. The snap ring style (inside snap ring retention) must match the yoke groove pattern -- OSR yokes have an external groove; ISR yokes have an internal groove. The 9951-23 requires a grease gun at installation and at regular service intervals. Correct installation torque on the strap kit or U-bolt is critical -- undertorqued straps allow the cap to walk under load.
Installation Notes for 9951-23
Before installing the 9951-23, clean the yoke bores of any rust, burrs, or old bearing material. The bearing cups must drop in by hand -- never drive them in with a hammer directly on the cup. Use a proper cross-and-bearing installation tool or a press. Driving a cup in at an angle cocks the needle bearings and destroys the 9951-23 before it ever sees load.
After installation, verify full rotation without binding. A binding cross indicates a cup is cocked or seated too deep. The 9951-23 should articulate freely through the full operating angle of your driveshaft before the vehicle is lowered off the lift.
Key Features
- Series: N/A series
- Cap dia: 1.181" -- must match yoke bore exactly
- Width: 2.290" -- controls yoke ear span
- Style: inside snap ring retention -- verify yoke groove type before ordering
- Greaseable -- zerk fitting included, service at regular intervals
- Brand: UDS
Specifications
- SKU: 9951-23U
- Part Number: 9951-23
- Brand: UDS
- Series: N/A
- Cap Dia 1: 1.181"
- Width 1: 2.290"
- Snap Ring Style: ISR
- Lube: Yes -- grease fitting
Additional information
| Style |
ISR |
|---|---|
| Cap dia 1 |
1.181 |
| Width 1 |
2.290 |
| Lube |
Y |
| Partn number |
9951-23 |
| Brand |
UDS |
| Series |
N/A |
