2-1-1313-4 Companion Flange Yoke – Bore: 1.250 , Keyway 0.312 , Pilot: F-2.375
$33.52
+50 in stock
15
People watching this product now!
Description
2-1-1313-4 UDS companion flange yoke. Bore 1.250″, keyway 0.312″, pilot F-2.375″, bolt circle 3.125″, OD 3.875″. Verify bore, keyway, and pilot against output shaft before ordering.
Full Description
2-1-1313-4 UDS Companion Flange Yoke – 1.250" Bore, 0.312" Keyway, 2.375" Pilot
The 2-1-1313-4 is a UDS companion flange yoke with a 1.250" bore diameter, 0.312" keyway, and a front pilot diameter of 2.375". The bolt circle diameter is 3.125" and outside diameter is 3.875".
Specifications
- Part Number: 2-1-1313-4
- Brand: UDS
- Bore Diameter: 1.250"
- Keyway: 0.312"
- Pilot Diameter: F-2.375"
- Bolt Circle Diameter: 3.125"
- Outside Diameter: 3.875"
When fitting the 2-1-1313-4, verify the output shaft diameter is 1.250" and the keyway width is 0.312" before pressing the flange onto the shaft. The front pilot diameter of 2.375" must match the companion flange receiver on the transmission or axle housing. The 3.125" bolt circle must align with the mating companion flange bolt pattern.
Confirm both the bore/keyway and pilot diameter dimensions against the transmission output shaft and companion flange specification before ordering. The 3.875" outside diameter sets the maximum clearance envelope for this flange yoke installation.
Additional information
| Brand | UDS |
|---|---|
| Partn number | 2-1-1313-4 |
| Pilot dia | 2.375 |
| Bolt circle dia | 3.125 |
| Bore dia | 1.250 |
| Keyway | 0.312 |
| Outside dia | 3.875 |
