3-1-32JK – Companion Flanges – 1.401″ Splines dia – 32 Splines – 4.250″ Bolt Circle Dia
$121.13
1 in stock
10 People watching this product now!
Description
3-1-32JK UDS flange yoke. 4-hole, 4.250″ bolt circle, 2.000″ pilot, ” CJ-to-face. Verify bolt circle and pilot before ordering.
Full Description
3-1-32JK UDS Flange Yoke
The 3-1-32JK is a series flange yoke manufactured by UDS. It bolts to a companion flange on the transmission, transfer case, or differential output using a 4-bolt pattern on a 4.250-inch bolt circle. The 2.000-inch pilot diameter registers the yoke concentrically against the companion flange to minimize runout.
The 4 bolt holes are -inch diameter on the 4.250-inch bolt circle. The center-U-joint-to-flange-face dimension is inches. This series yoke accepts a U-joint in the yoke ears — the ear bore is machined specifically for the cap diameter. Application note: Front 2007-2017 JEEP JK T-case Adapter.
Specifications
- Part Number: 3-1-32JK
- Brand: UDS
- Bolt circle dia: 4.250
- Hub dia: 1.943
- Notes: Front 2007-2017 JEEP JK T-case Adapter
- Pilot dia: 2.000
- Splines count: 32
- Splines dia: 1.401
- Through hole: 2.000
- Bolt Holes: 4
- Face to end: 3.810
Fitment & Installation Notes
Before ordering the 3-1-32JK, measure the bolt circle diameter and pilot diameter on the companion flange. The bolt circle (4.250") and pilot (2.000") must match exactly. A U-joint is required — do not install a different-series joint in these ears.
Browse the complete Companion Flanges catalog including circular and rectangular bolt patterns across and adjacent series.
Additional information
| Bolt circle dia | 4.250 |
|---|---|
| Hub dia | 1.943 |
| Notes | Front 2007-2017 JEEP JK T-case Adapter |
| Partn number | 3-1-32JK |
| Pilot dia | 2.000 |
| Splines count | 32 |
| Splines dia | 1.401 |
| Through hole | 2.000 |
| Bolt Holes | 4 |
| Face to end | 3.810 |
