6.5-4-3591-1 – End Yoke – 1810 Series – 2.390″ Splines Dia – 2.875″ Hub Dia
$153.85
1 in stock
10 People watching this product now!
Description
1810 series 6.5-4-3591-1 end yoke. 2.390″ x 46 spline | 2.875″ hub dia | 5.500″” CJ-to-end | 2.750″ bore. HR retention. Direct swap for axle or T-case output.
Full Description
The 6.5-4-3591-1 end yoke slides onto the axle or transfer case output shaft, locking onto the splines and becoming the u-joint cradle at that end of the driveshaft.
6.5-4-3591-1 End Yoke -- 1810 Series Spline & Fitment
The 1810 series is the standard for Class 7-8 commercial vehicles and heavy industrial equipment.
Dimensions on the 6.5-4-3591-1 end yoke: 2.390" x 46 spline | 2.875" hub dia | 5.500"" CJ-to-end | 2.750" bore. HUB DIAMETER NOT GROUND. Verify spline count and diameter against your axle or transfer case output shaft.
The hub diameter and CJ-to-end measurement determine clearance and working angle -- both matter on lifted vehicles.
Key Features
- Series: 1810 -- Class 7-8 commercial vehicles and heavy industrial equipment
- Spline: 2.390" x 46 -- must match axle/T-case shaft exactly
- Hub dia: 2.875" -- outer dimension, affects clearance in yoke bore
- CJ-to-end: 5.500"" -- affects driveshaft working length and angle
- Bore: 2.750" -- confirm against shaft OD
- Retention: HR -- verify against your yoke configuration
- Note: HUB DIAMETER NOT GROUND
Specifications
- SKU: 6.5-4-3591-1
- Brand: UDS
- Series: 1810
- Spline Dia: 2.390"
- Spline Count: 46
- Hub Dia: 2.875"
- CJ to End: 5.500""
- Through Hole: 2.750"
- Style: HR
- Notes: HUB DIAMETER NOT GROUND
Additional information
| Cj to end | 5.500" |
|---|---|
| Hub dia | 2.875 |
| Notes | HUB DIAMETER NOT GROUND |
| Partn number | 6.5-4-3591-1 |
| Series | 1810 |
| Splines count | 46 |
| Splines dia | 2.390" |
| Style | HR |
| Through hole | 2.750" |
