UDS- 5-1330X Universal Joint – 1330 Series Lube for Life Premium Non-Greasable HEAVY DUTY COMES WITH 2 SNAP RINGS SIZES

5-1330X UDS 1330 Series Sealed Universal Joint – OSR Style

The 5-1330X is a UDS 1330 series sealed (lube-for-life) universal joint. Cap diameter is 1.063" and width is 3.625". OSR (outside snap ring) retention style is used. This unit is sealed — no grease fitting — and ships with two snap ring sizes to accommodate yoke ear groove variation. Includes 2 snap ring sizes.

Specifications

• Part Number: 5-1330X
• Brand: UDS
• Series: 1330
• Cap Diameter: 1.063"
• Width: 3.625"
• Style: OSR
• Lube: No – sealed, lube for life
• Includes: 2 snap ring sizes

When installing the 5-1330X, verify yoke ear bores are dimensioned for 1.063" cap diameter and 3.625" span. Because this joint is sealed at the factory, no re-greasing is possible — the service interval is determined by total wear rather than lube maintenance. The included two snap ring sizes allow fitment into yokes with slightly different groove depths. The 1330 series sits between the 1310 and 1350 in the torque capacity range. Confirm that both mating yokes are 1330 series before installation. The OSR retention style requires undamaged snap ring grooves — do not use yokes with wallowed or cracked groove walls with the 5-1330X.
