3R80-50 Center Support Bearing Chevy S10 / GMC Sonoma / Dodge Dakota 212088-1X ID: 1.378″ Square
$22.74
+50 in stock
15
People watching this product now!
Description
3R80-50 center support bearing for GM. Bearing ID 1.378″, mount holes ” C-to-C. Verify stub shaft OD and bracket spacing.
Full Description
3R80-50 Center Support Bearing - GM
The 3R80-50 is a center support bearing manufactured by UDS. In a two-piece driveshaft layout, the center support bearing carries the midship stub shaft at the point where the front and rear driveshaft sections meet. The bearing presses into a rubber-isolated housing that bolts to the vehicle frame or crossmember. This bearing is catalogued for GM applications.
The bearing inner bore (ID) is 1.378 inches — this must match the outer diameter of the midship stub shaft exactly. Even a small mismatch causes either interference fit problems or excessive play. The centerline-to-base dimension is 2.250 inches, measured from the bearing centerline to the bottom of the mounting bracket; this determines the working angle of the front driveshaft section. Chevrolet GMC, Square type used with double CV, 6.40mm X 14.30mm mounting bolts, square steel bracket.
Specifications
- Part Number: 3R80-50
- Brand: UDS
- Application: GM
- Bearing id: 1.378
- Center bearing to base: 2.250
- Ctr to ctr of mount holes: 6.625
- Notes: Chevrolet GMC, Square type used with double CV, 6.40mm X 14.30mm mounting bolts, square steel bracket
Fitment & Installation Notes
Before ordering the 3R80-50, measure the midship stub shaft OD and confirm it matches the 1.378-inch bore. Also verify the frame bracket hole spacing matches the -inch center-to-center dimension. The rubber isolator in the housing should be replaced if cracked or oil-contaminated, as a degraded isolator transmits driveshaft vibration directly to the chassis.
View the full range of Center Support Bearings for two-piece driveshaft applications.
Additional information
| Application | GM |
|---|---|
| Bearing id | 1.378 |
| Center bearing to base | 2.250 |
| Ctr to ctr of mount holes | 6.625 |
| Notes | Chevrolet GMC, Square type used with double CV, 6.40mm X 14.30mm mounting bolts, square steel bracket |
| Partn number | 3R80-50 |
