211260X – Center Support Bearing – 1350/1410 Series – 1.574″ ID – 2.250″ Center Bearing To Base
$34.87
10 in stock
20
People watching this product now!
Description
211260X center support bearing, 1350, 1410 series. 1.574″ inner dia | 2.250″ center-to-base | 6.625″ mount hole spacing. Verify inner diameter and mount hole spacing before ordering.
Full Description
Driveshaft vibration on 2-piece shafts almost always traces back to the center support bearing. The 211260X is the replacement -- correct inner diameter, correct bracket dimensions.
211260X Center Support Bearing -- 1350, 1410 Series Dimensions
Specs on the 211260X center support bearing: 1.574" inner dia | 2.250" center-to-base | 6.625" mount hole spacing. Similar to 210866-1X but without dust shields. Built for 1350, 1410 series applications. The inner diameter must match your midshaft stub -- too loose and the bearing walks; too tight and it won't press on.
Mount hole center-to-center spacing is the most overlooked spec on CSBs. If the holes don't match your crossmember bracket, the bearing will be offset and the shaft will run off-center.
Key Features
- Application: 1350, 1410 series -- verify your driveshaft series matches
- Bearing inner dia: 1.574" -- must match midshaft stub OD exactly
- Center-to-base: 2.250" -- height from shaft centerline to mounting surface
- Mount hole spacing: 6.625" -- must match crossmember bracket hole pattern
- Rubber isolator included -- absorbs vibration, reduces NVH at the midshaft
- Complete assembly -- bearing race, rubber mount, and bracket in one unit
- Note: Similar to 210866-1X but without dust shields
Specifications
- SKU: 211260X
- Brand: UDS
- Application: 1350, 1410 Series
- Bearing ID: 1.574"
- Center to Base: 2.250"
- Mount Hole Spacing: 6.625"
- Notes: Similar to 210866-1X but without dust shields
Additional information
| Application |
1350, 1410 |
|---|---|
| Bearing id |
1.574 |
| Center bearing to base |
2.250 |
| Ctr to ctr of mount holes |
6.625 |
| Partn number |
211260X |
| Notes |
Similar to 210866-1X but without dust shields |
