2-4-0523 – End Yoke – 1310 Series – 2.125″ Hub Dia – 2.562″ Cj To End
$46.30
6 in stock
18
People watching this product now!
Description
2-4-0523 end yoke, 1310 series. KEYWAY- 0.312 x ROUND BORE spline | 2.125″ hub dia | 2.562″ CJ-to-end. Splined bore — verify count and diameter before ordering.
Full Description
A sloppy end yoke causes driveline clunk and accelerated u-joint wear. The 2-4-0523 end yoke is the direct replacement -- correct spline count, correct series.
2-4-0523 End Yoke Specifications & Series
The 2-4-0523 end yoke -- KEYWAY- 0.312 x ROUND BORE spline | 2.125" hub dia | 2.562" CJ-to-end. KEYWAY LOCATION AT 12.
The 1310 series is the standard for light-duty trucks -- F-150, Silverado 1500, Jeep Wrangler, Ram 1500. Count the splines on your shaft. If the shaft was replaced or the axle swapped, the spline count may not match the original.
Key Features
- Series: 1310 -- light-duty trucks -- F-150, Silverado 1500, Jeep Wrangler, Ram 1500
- Spline: KEYWAY- 0.312 x ROUND BORE -- must match axle/T-case shaft exactly
- Hub dia: 2.125" -- outer dimension, affects clearance in yoke bore
- CJ-to-end: 2.562" -- affects driveshaft working length and angle
- Retention: RB -- verify against your yoke configuration
- Note: KEYWAY LOCATION AT 12
Specifications
- SKU: 2-4-0523
- Brand: UDS
- Series: 1310
- Spline Dia: KEYWAY- 0.312
- Spline Count: ROUND BORE
- Hub Dia: 2.125"
- CJ to End: 2.562"
- Style: RB
- Notes: KEYWAY LOCATION AT 12
Additional information
| Cj to end |
2.562 |
|---|---|
| Hub dia |
2.125 |
| Notes |
KEYWAY LOCATION AT 12 |
| Partn number |
2-4-0523 |
| Series |
1310 |
| Splines count |
ROUND BORE |
| Splines dia |
KEYWAY- 0.312 |
| Style |
RB |
