2-2-1339 Flange Yoke 1310 series , 6 x 0.441Holes on 3.307 Bolt Circle Diameter , 2.244 Female Pilot
$19.31
7 in stock
13
People watching this product now!
Description
2-2-1339 1310 series flange yoke, 6 holes on 3.307 in bolt circle, 0.345 in holes, 2.244 in female pilot, 1.968 in CJ-to-flat. Verify bolt circle and pilot before ordering.
Full Description
2-2-1339 1310 Series Flange Yoke — 6-Bolt, Female Pilot
The 2-2-1339 is a 1310 series flange yoke with a 6-bolt pattern. The bolt circle diameter is 3.307 inches with 0.345-inch bolt holes, the pilot diameter is 2.244 inches female (2.244-F), and the centerline-to-flat dimension is 1.968 inches. This yoke bolts to the companion flange at the output shaft and accepts a 1310 series U-joint at its ears.
Specifications
- Part Number: 2-2-1339
- Series: 1310
- Bolt Circle Diameter: 3.307 in
- Bolt Hole Diameter: 0.345 in
- Bolt Holes: 6
- Pilot Diameter: 2.244 in (female)
- Center U-Joint to Flat: 1.968 in
When fitting the 2-2-1339, verify the companion flange presents a 3.307-inch bolt circle with 6 holes at 0.345-inch diameter. The 2.244-inch female pilot registers over the male pilot on the companion flange; measure the companion flange male pilot OD and confirm it falls within the bore tolerance before installation. The 1.968-inch CJ-to-flat is shorter than the 1350 series variant (2-2-1339B at 2.625 in) — this is the key dimensional distinction between the two part numbers.
The 2-2-1339 is a 1310 series yoke, one of the most common flange configurations in North American light-duty truck and SUV drivelines. Use 1310 series U-joints at this yoke. Verify bolt circle diameter and pilot before ordering.
Additional information
| Bolt circle dia | 3.307 |
|---|---|
| Bolt hole dia | 0.345 |
| Cj to flat | 1.968 |
| Partn number | 2-2-1339 |
| Pilot dia | 2.244-F |
| Series | 1310 |
| Bolt Holes | 6 |
