UDS T35-ALFY-07 6-Bolt Adapter – High-performance Flange Yoke for 1350 Series U-Joints
$348.01
1 in stock
12 People watching this product now!
Description
T35-ALFY-07U UDS 1350 series 6-bolt 7075-T6 aluminum flange yoke. 108mm CVJ conversion for GM CTS-V, Mopar Charger/Challenger, BMW. 4.251″ pilot, 3.701″ bolt circle.
Full Description
T35-ALFY-07U UDS 1350 Series 6-Bolt Adapter Flange Yoke — GM CTS-V, Mopar, BMW CVJ Conversion
The T35-ALFY-07U is a 1350 series 6-bolt adapter flange yoke manufactured by UDS from 7075-T6 aluminum. It is designed for 108mm CVJ conversions across multiple vehicle platforms including GM CTS-V, Mopar Charger/Challenger/300, and BMW. The pilot diameter is 4.251 inches, the bolt circle diameter is 3.701 inches, and the bolt hole diameter is 0.425 inches with 6 holes. The CJ-to-flat dimension is 3.440 inches.
Specifications
- Part Number: T35-ALFY-07U
- Brand: UDS
- Series: 1350
- Pilot Diameter: 4.251"
- Bolt Circle Diameter: 3.701"
- Bolt Hole Diameter: 0.425"
- Bolt Holes: 6
- CJ to Flat: 3.440"
- Notes: 7075-T6 Aluminum Flange; 108mm CVJ conversion; fits GM CTS-V, Mopar Charger/Challenger/300/etc., BMW
When fitting the T35-ALFY-07U, confirm the companion flange on the transmission or differential uses a 4.251-inch pilot and a 3.701-inch bolt circle with 6 x 0.425-inch holes. The 108mm CVJ conversion geometry means the bolt pattern is matched to the 108mm CVJ flange found on CTS-V, Charger/Challenger/300, and BMW applications — verify your specific vehicle's flange dimensions before ordering.
The T35-ALFY-07U is constructed from 7075-T6 aluminum, which offers higher strength-to-weight ratio than 6061-T6 and is appropriate for the high-torque performance applications this flange is designed for. The 3.440-inch CJ-to-flat dimension is identical to the T35-ALFY-10U, but the bolt pattern and pilot differ — confirm the correct part for your specific vehicle platform.
Additional information
| Partn number | T35-ALFY-07 |
|---|---|
| Pilot dia | 4.251 |
| Bolt circle dia | 3.701 |
| Bolt hole dia | 0.425 |
| Series | 1350 |
| Brand | UDS |
| Notes | 7075-T6 Aluminum Flange, 108mm CVJ conversion, multiple apps: GM CTS-V, Mopar Charger/Challenger/300/etc. BMW |
| Bolt Holes | 6 |
| Cj to flat | 3.440 |
